Aventon Abound SR
$1,899.00
Skip to product information
SCHEDULE CONSULTATION
Aventon Abound SR
$1,899.00
Introducing the all-new Abound SR—the enhanced cargo ebike built to carry anything and tackle every challenge. Whether you're cruising through the streets or bike pooling with a friend, the Abound SR is always ready for any action. Its compact frame keeps you agile, while advanced security† and GPS† features give you total peace of mind.
Outfitted with an adjustable quill stem, suspension seatpost, and cutting-edge theft deterrent features†, every ride is smooth, secure, and stress-free.
General Info
Weight 80 lbs
Total Weight Limit 440 lbs
Rider Height 4'11" - 6'3"
Ebike Class Class 2 Ebike
Ideal Use Cargo & Utility
Pedal Assist 3 Levels (with Ride Tune Customization)
Safety Certifications UL and TUV Safety Certified
UL 2849
Range Up to 60 miles
Battery Safety Certifications Certified to UL 2271
Water Resistance Bike - IPX5 // Components - IPX6
Frame Style Step-Through
Frame 6061 Aluminum Alloy with Internal Battery. One piece - Diecast aluminum front triangle
Ebike System Motor Torque 80Nm
ECU Aventon ECU Module featuring wired CAN communication, GPS positioning support, wireless Bluetooth connectivity, and cellular communication capabilities
Throttle
Aventon LH Handlebar Mounted
Sensors
Double Sided Bottom Bracket Torque Sensor
Charger
Aventon 4A 42V
Display
Aventon BC147
Speed
Class 2
Battery
Aventon 36V, 20Ah, 733Wh, LG 21700 cells
Motor
Shengyi 36V 750w Hub Drive with 6 speed sensors (1188W peak)
Brakes
Rear Brake Rotor
Tektro 203mm 6 bolt
Front Brake
Tektro HD-E3520 hydraulic disc brakes
Rear Brake
Tektro HD-E3520 hydraulic disc brakes
Front Brake Rotor
Tektro 180mm 6 bolt
Drivetrain
Chain
122 Link, 8 Speed
Chainring
52 tooth
Crankset
3pc, 165mm crank arm
Rear Derailleur
Shimano Altus RD-M310 8 Speed
Shift Lever
Shimano SL-M315-8R 8 Speed
Cassette
Shimano CS-HG200-8 8 speed Cassette, 12-32T
Pedals
9/16" Composite Platform
Chainring BCD
130
Cockpit
Saddle
Aventon by SelleRoyal
Seatpost
30.9mm Aventon Suspension Seatpost with 50mm travel
Handlebars
BMX Style, 31.8mm bar clamp, 680mm width
Stem
Quill Stem with 31.8mm bar clamp diameter, 40mm length, and 140mm of vertical adjustment
Seat Clamp
34.9mm Quick Release
Grips
Lock-on ergonomic
Included Accessories
Rear Rack
Included
Kickstand
Included: E-lock
Rear Wheel Mesh Guards
Included
Rear Rack Weight Limit
143 lbs
Wheelset
Tires
20 x 3.0 urban tire with reflective sidewalls
Wheels
20-inch, 12-gauge, 36-hole, double-wall aluminum, black
